产品概述
SparkLAN WPET-239ACN(BT) 是一款高度集成的单芯片无线 LAN (WLAN)、BT Combo USB 模块，支持 2 流 802.11ac 解决方案，具有多用户 MIMO（多输入多输出）无线 LAN (WLAN) . 它在单芯片 USB ?？橹屑闪?2Tx2R WLAN MAC、基带和双频射频。WPET-239ACN(BT) 通过一个 USB 端口为 M2M（机器对机器）连接产品/设备提供了一种经济高效的解决方案。
WPET-239ACN(BT) 802.11ac/abgn 2Tx2R USB WLAN/BT 组合?？?，具有各种 USB 输入格式和内部打印或外部 RF 天线连接器，用于高性能无线 LAN 和 BT 设备。它旨在以低功耗提供完整的 M2M 连接和出色的性价比，并增强稳健系统和应用程序的优势。
适用应用
应用包括便携式手持设备、瘦客户端计算机、医疗设备、网络安全和监控、3D打印机、电视、机顶盒、POS、数字标牌、游戏机、机器人机械、工业平板电脑等。
参数特性
STANDARD
|
| WI-FI |
IEEE 802.11ac/a/b/g/n |
| Chipset |
Realtek RTL8822CU |
| Host Interface |
WLAN : USB |
RADIO
|
| Antenna |
2 x IPEX MHF1 connectors(ANT0仅用于WLAN，ANT1用于WLAN+BT) |
| Operating Frequency |
802.11ac/a/b/g/n ISM Band |
| 2.412GHz~2.484GHz
5.150GHz~5.850GHz
*Subject to local regulations
|
MODULATIONS
|
| 802.11b |
DSSS (DBPSK, DQPSK, CCK) |
| 802.11g |
OFDM (BPSK, QPSK, 16-QAM, 64-QAM) |
| 802.11n |
OFDM (BPSK, QPSK, 16-QAM, 64-QAM) |
| 802.11a |
OFDM (BPSK, QPSK, 16-QAM, 64-QAM) |
| 802.11ac |
OFDM (BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM) |
POWER & SENSITIVITY
|
| WiFi |
Power – TX (± 2dBm) |
Sensitivity – RX |
| 11b @11Mbps |
17dBm |
≤ -76dBm |
| 11g @ 54Mbps |
16dBm |
≤ -65dBm |
| 11gn HT20 @ MCS 7 |
15dBm |
≤ -64dBm |
| 11gn HT40 @ MCS 7 |
15dBm |
≤ -61dBm |
| 11a @ 54Mbps |
15dBm |
≤ -70dBm |
| 11an HT20 @ MCS 7 |
14dBm |
≤ -60dBm |
| 11an HT40 @ MCS 7 |
14dBm |
≤ -60dBm |
| 11ac VHT80 @ MCS 9 |
11dBm |
≤ -51dBm |
POWER CONSUMPTION
|
| Continue TX |
600mA |
| Continue RX |
350mA |
ENVIRONMENTAL
|
| Operating Voltage |
DC 3.3V |
| Temperature Range |
-20~ +70°C (Operating) |
-40 ~ +85°C (Storing) |
| Humidity(Non-Condensing) |
5~ 95% (Operating) |
5 ~ 90% (Storing) |
SIZE
|
| Dimension (MM) |
29.9mm(±0.3mm) x 26.6mm(±0.3mm) x 3.0mm(±0.3mm) |
| Weight |
2.76g |
SOFTWARE
|
| Driver |
Windows |
| Linux |
| Android |
| Security |
64/128-bits WEP, WPA, WPA2,WPA3,802.1x |
Miscellaneous
|
| Warranty Period |
12 Month |
| HS Code |
8517620050 |
认证
 |
 |
 |
 |
| USA |
EU Region |
Japan |
Canada |
环境合规
 |
 |
|
|
| ROHS |
REACH |
|
|
